DC3-5V 4Way Relay Automatic Watering Device Capacitive Soil Moisture Sensor Suitable For Monitor Garden Soil Moisture DIY Kit
Product Features
Easy to use, this automatic watering DIY kit is perfect for monitoring soil moisture as it automatically waters your plants and flowers
Automatic irrigation system that combines a pump, pipe, soil moisture sensor and 4-channel 5V relay module in one plant irrigation system, including a kit for the entire Arduino DIY drip irrigation system
Capacitive sensors that are placed in the soil around your plants, and through the sensors and the main board, you can communicate with your plants. Whether your plants need more water to hydrate to see if they are dehydrated
Always take care of your plants, the system can automatically water your plants. When your soil is too dry, the pump will kick in and water will flow into the tubes and containers. When you go on vacation, you don't have to worry about your plants
Perfect for personal DIY production
Specifications
Capacitive soil moisture sensor.
Operating voltage: 3.3~5.5 VDC
Output voltage: 0~3.0 VDC
Interface: PH2.54-3P
Pin: Analog signal output, GND, VCC
1 way 5V relay module.
VCC : Connected to 5V positive power supply
GND: Connected to 5V negative power supply
Mini pump
DC voltage: DC3-5V
Outlet outside diameter: 0.29 inch/7.5mm
Outlet inner diameter: 0.17 inches / 4.5mm
Water inlet diameter: 0.19 inches/5mm
Drive mode: brushless DC design, mesh drive
300 hours continuous working life
Vinyl tubing
Material: PVC
Length: 39.37 inches/400cm
Material: ABS
Shipping list
Capacitive earth humidity sensor X4
4 way 5V relay module X1
Water pump X4
4M water pipe X1
